SBOM Workbench

The SBOM Workbench is a graphical user interface to scan and audit source code using SCANOSS API.

Auditing your source code for license compliance has never been easier. Simply scan your source code directory to find and identify open source components. Generate your SPDX-Lite software bill of materials (SBOM) with the press of a button.

Find prebuilt binaries for all platforms over at: Software Transparency Foundation

Prerequisites

• Node.js >=v22.12.0
• NPM (Node Packages Manager)

We strongly recommend handling your node versions using nvm

Install

npm install --legacy-peer-deps

Please note that you should include the --legacy-peer-deps parameter in the installation command. This is because @mui/styles is not compatible with React 18. You can find more information about this at https://mui.com/system/styles/basics/.

Troubleshooting

SBOM Workbench uses node-gyp to compile SQLite3 native module. This module uses "node-pre-gyp" to download the prebuilt binary for your platform instead you need build from source. In case it does not exist for your platform, node-gyp going to build it.

Depending on your operating system, you will need prepare the correct environment to run node-gyp: See https://github.com/nodejs/node-gyp#installation

Starting Development

Start the app in the dev environment:

npm start

For live reloading you can use npm run start --watch to run the app using Electronmon. Warning: this tool has a high memory consumption.

Packaging for Production

To package apps for the local platform:

npm run package

Multi-language (i18n)

SBOM Workbench is multi-language enabled. To contribute a new language please see our internationalization documentation.

Workbench Configuration

SBOM Workbench support advanced settings. All the configurations needs to be included in the global config file ~/.scanoss/sbom-workbench-settings.json

Scanner parameters

"SCANNER_CONCURRENCY_LIMIT": "<integer>" Number of threads to use while scanning (optional - default 5)

"SCANNER_POST_SIZE": "<intenger>" Number of kilobytes to limit the post to while scanning (optional - default 16)

"SCANNER_TIMEOUT": "<integer>" Timeout (in seconds) for API communication (optional - default 300)

Proxy settings

You might need to specify proxy settings depending on how your network is configured

"PROXY": "<proxy_ip_address>:<proxy_port>"

If your network is using a proxy with SSL interception you can include your certificate in the configuration

"CA_CERT": "<certificate_path>"

You can disable any SSL errors, to do so you can change this option to true

"IGNORE_CERT_ERRORS": true

Local Cryptography Detection in SBOM-Workbench

Overview

Local cryptography can be detected by SBOM-Workbench when an API key is configured. This feature enables the detection of cryptographic algorithms and libraries within a codebase.

Default and Custom Detection Rules

Default rules are provided for the detection of cryptographic algorithms and libraries. However, custom rules may be defined at the root of the project to be scanned.

Custom Rule Files

Custom rules can be defined through the following JSON files at the project root:

• Algorithm detection rules: scanoss-crypto-algorithm-rules.json. See: Algorithm Rules Sample
• Library detection rules: scanoss-crypto-library-rules.json

Rule File Structure

Algorithm Rules Structure

The structure of scanoss-crypto-algorithm-rules.json should be formatted as follows:

[
   {
     "algorithmId": "md5",
     "algorithm": "MD5 Message-Digest Algorithm",
     "strength": "128",
     "keywords": [
       "md5_file",
       "md5",
       "md5crypt",
       "aprcrypt",
       "md5_encrypt",
       "md5_block_data_order",
       "ossl_md5_sha1_",
       "MD5_Init"
     ]
   }
 ]

Library Rules Structure

The structure of scanoss-crypto-library-rules.json should be formatted as follows:

[
  {
    "id": "library/webcrypto",
    "name": "Web Cryptography API",
    "description": "A JavaScript API for performing basic cryptographic operations in web applications.",
    "keywords": [
      "window.crypto.subtle",
      "crypto.subtle.",
      "crypto.getRandomValues",
      "NodeWebCrypto",
      "WebCryptoAPI"
    ],
    "url": "https://developer.mozilla.org/en-US/docs/Web/API/Web_Crypto_API",
    "category": "library",
    "purl": "pkg:generic/webcrypto",
    "tags": [
      "JavaScript"
    ]
  }
 ]

SCANOSS Settings File

SCANOSS provides a settings file to customize the scanning process. The settings file is a JSON file that contains project information and BOM (Bill of Materials) rules. It allows you to include, remove, or replace components in the BOM before and after scanning.

Settings

The scanoss.json object allows you to configure various aspects of the scanning process. Currently, it provides control over which files should be skipped during scanning through the skip property.

BOM Rules

The bom section defines rules for modifying the BOM before and after scanning. It contains three main operations:

1. Include Rules

Rules for adding context when scanning. These rules will be sent to the SCANOSS API meaning they have more chance of being considered part of the resulting scan.

{
    "bom": {
        "include": [
            {
                "path": "/path/to/file",
                "purl": "pkg:npm/[email protected]",
                "comment": "Optional comment"
            }
        ]
    }
}

2. Remove Rules

Rules for removing files from results after scanning. These rules will be applied to the results file after scanning. The post processing happens on the client side.

{
    "bom": {
        "remove": [
            {
                "path": "/path/to/file",
                "purl": "pkg:npm/[email protected]",
                "comment": "Optional comment"
            }
        ]
    }
}

3. Replace Rules

Rules for replacing components after scanning. These rules will be applied to the results file after scanning. The post processing happens on the client side.

{
    "bom": {
        "replace": [
            {
                "path": "/path/to/file",
                "purl": "pkg:npm/[email protected]",
                "replace_with": "pkg:npm/[email protected]",
                "license": "MIT",
                "comment": "Optional comment"
            }
        ]
    }
}

Matching Rules

1. Full Match: Requires both PATH and PURL to match. It means the rule will be applied ONLY to the specific file with the matching PURL and PATH.
2. Partial Match: Matches based on either:
   • PURL only (PATH is optional). It means the rule will be applied to all files with the matching PURL.

Example Configuration

Here's a complete example showing all sections:

{
    "bom": {
        "include": [
            {
                "path": "src/lib/component.js",
                "purl": "pkg:npm/[email protected]",
                "comment": "Include lodash dependency"
            }
        ],
        "remove": [
            {
                "purl": "pkg:npm/[email protected]",
                "comment": "Remove deprecated package"
            }
        ],
        "replace": [
            {
                "path": "src/utils/helper.js",
                "purl": "pkg:npm/[email protected]",
                "replace_with": "pkg:npm/[email protected]",
                "license": "MIT",
                "comment": "Upgrade to newer version"
            }
        ]
    }
}

Usage

You can add your 'scanoss.json' on the root of your project

Command Line Interface (CLI)

SBOM Workbench includes a CLI for managing configuration without launching the graphical interface. This is useful for automation, scripting, and headless environments.

Getting Help

# Show all available commands
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage --help

Platform Notes

Windows

On Windows, Electron applications run as GUI processes without a console attached by default. This means:

• Commands that modify configuration work correctly (config init, config api add, config api rm, config api default)
• Commands that display output won't show results (--help, --version, config api list) - there is no visible output in cmd.exe or PowerShell

Windows examples:

:: Initialize configuration
sbom-workbench-1.27.0-win-x64-app.exe config init

:: Add an API
sbom-workbench-1.27.0-win-x64-app.exe config api add --url=https://api.scanoss.com --key=YOUR_API_KEY --default

:: Remove an API by index
sbom-workbench-1.27.0-win-x64-app.exe config api rm --index=1

:: Set default API
sbom-workbench-1.27.0-win-x64-app.exe config api default --index=0

Tip: To view your configured APIs on Windows, open %USERPROFILE%\.scanoss\sbom-workbench-settings.json in a text editor.

Linux / macOS

On Linux and macOS, CLI output displays normally in the terminal. Both parameter syntaxes work:

# Space syntax
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api add --url https://api.scanoss.com --key YOUR_API_KEY

# Equals syntax (also works)
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api add --url=https://api.scanoss.com --key=YOUR_API_KEY

Ubuntu 24.04+

On Ubuntu 24.04 and newer, the AppImage sandbox may not work due to kernel restrictions. If you encounter sandbox errors, disable it by setting the environment variable:

export ELECTRON_DISABLE_SANDBOX=1
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config init

Configuration Commands

Initialize Configuration

Creates the default configuration file at ~/.scanoss/sbom-workbench-settings.json:

./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config init

Note: This command will fail if a configuration file already exists.

API Management

The CLI allows you to manage multiple API configurations for connecting to different SCANOSS servers.

List Configured APIs

Display all configured APIs with their indices:

./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api list

Example output:

Configured APIs:
[0] https://api.scanoss.com [key set] (default)
[1] https://custom.scanoss-server.com

Add an API

Add a new API configuration:

# Add API with URL only (public SCANOSS API)
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api add --url https://api.scanoss.com

# Add API with URL and API key
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api add --url https://api.scanoss.com --key YOUR_API_KEY

# Add API and set it as the default
./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api add --url https://custom.server.com --key YOUR_KEY --default

Remove an API

Remove an API configuration by its index:

./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api rm --index 1

Note: If you remove the default API, the default will automatically be adjusted to the last available API.

Set Default API

Change which API is used by default:

./sbom-workbench-1.27.0-linux-x86_64-app.AppImage config api default --index 0

Collaborative Workspace

The SBOM Workbench includes support for a collaborative workspace, a feature designed to enhance teamwork. View more details here.

Code Viewer Keyboard Shortcuts

The code viewer supports the following keyboard shortcuts for zooming:

Action	macOS	Windows/Linux
Zoom In	Cmd + +	Ctrl + +
Zoom Out	Cmd + -	Ctrl + -
Reset Zoom	Cmd + 0	Ctrl + 0

You can also zoom using Ctrl/Cmd + Mouse Wheel. Press F1 to open the command palette and see all available commands.

Contributing

SBOM Workbench is an open source project, and we love to receive contributions from our community. There are many ways to contribute. For more information see the Contributing Guide and Code of Conduct.

Docs

This project was made using Electron React Boilerplate

See docs and guides here
